Hurray, all domestic Rv refrigerator troubleshooting problems has now been fixed. There are certain differences between refrigerators used in homes and those used in recreational vehicles; these differences are notably common in RVs.

For instance, the cooling system in an RV refrigerator is different from that of a conventional refrigerator.

It’s possible that maintaining and fixing the refrigerator in your RV will be more difficult than you anticipate.

You should be familiar with the inner workings of a Domestic RV refrigerator, as well as its proper operation and the solutions to a variety of problems, before attempting to troubleshoot it.

Domestic Rv Refrigerator Troubleshooting

How Dometic RV Refrigerator Works

A combination of heat and chemical reactions involving ammonia, hydrogen gas, and water are required for the operation of the refrigerator. The heat causes the mixture of ammonia and water to boil, and as a result, ammonia vapor rises and travels along the cooling system. The vapor becomes a liquid, and then the liquid enters the evaporator where it is evaporated.

While doing so, the device also continues to circulate water and ammonia and uses very modest amounts of propane to cool the refrigerator. The original mixture of ammonia and water is heated by electricity, which causes it to convert into vapor. After some time has passed, the ammonia vapor recombines with the water vapor and begins to drip into a pool of liquid water and ammonia mixture.

Why is My Dometic RV fridge not Cooling?

• Failing to park your vehicle in a level position can be one of the problems that leads to your refrigerator not working properly.

The heat from an RV refrigerator is taken out and absorbed by a chemical solution, and the solution relies on gravity to move through the coils.

This makes an RV refrigerator distinct from other types of refrigerators. Therefore, in order for the refrigerator in the RV to function properly, it needs to be at a level.

• Once more, ensure that the burner orifice is free of any debris. If the orifice is unclean, the flame will be feeble, and this will prevent the RV refrigerator from being cooled. If the orifice is unclean, giving it a thorough cleaning will cause the flame to become blue and become more vigorous.

• Inadequate ventilation in hot weather; install additional refrigerator fans to compensate for the lack of ventilation.

How to Reset a Domestic RV Refrigerator

While you are holding down the on/off mode button for three seconds, press the + button. At a later time, turn off the system by repeatedly pressing the on/off button to finish the operation.

Why Dometic RV Fridge not Cooling When Powered by Electricity

If the refrigerator in your RV is not maintaining a cool temperature, the circuit breakers may have tripped.

You should attempt to reset the circuit breakers that have tripped on the refrigerator so that it may once again be powered by electricity.

If there are no tripped circuit breakers, the electric refrigerator’s heating element may be defective and will need to be replaced for the appliance to function properly when using electricity.

Conduct a voltage check on the heating element while it is still connected to the device.

Related: Gm VSP Login

If there is a voltage on one wire but not the other, then the element may have been destroyed, which would result in a break in the path that the voltage takes.

You need to get your RV checked out at a reputable dealership as soon as possible so that the problem may be handled by experts.

Why The Dometic RV Refrigerator Is Not Cooling When Running on Gas

There are a few potential explanations for why your Dometic RV’s gas system isn’t functioning properly, including the following:

• If you have low gas pressure or no gas at all, you should check your gas pressure and refuel your vehicle if necessary.

• A clogged burner jet; clean the burner thoroughly, removing any dirt or corrosion that may be causing interference with the burner system.

• If the burner nozzle is clogged, clear the debris and soot off of it, and then try turning the refrigerator’s heat source to gas.

• If your hose pipe is clogged, try clearing the debris out of the pipe with a little, thin wire, or you might even use a vacuum.

• Blocked or soot-covered gas flue – remove all of the dust and soot from the gas flue, and the refrigerator ought to start working again.

• A damaged or soiled magnetic seal on the refrigerator door – wipe down the seal on your refrigerator and adjust the door hinge so that the seal is properly positioned.

Domestic Rv Refrigerator Troubleshooting no Power

• There is a blown fuse to the refrigerator or blown fuses in the refrigerator’s power module. If this is the case, you will need to purchase additional fuses and replace the blown ones; however, if you are unable to do so, you should seek the assistance of a professional.

• If you suspect that the issue may be related to the wiring that leads to your refrigerator, have a trained professional examine it for you.

• If the refrigerator is being powered by batteries, the voltage may be low; as a result, you will need to get brand-new batteries for the appliance.

Dometic RV Fridge not Cold Enough

There may be a problem with your refrigerator, which is why your RV isn’t getting cold enough; before getting it checked out, give these troubleshooting tips a shot:

• The cold air in the fridge isn’t getting circulated; try installing an RV fridge vent fan to increase the efficiency of your refrigerator in air circulation.

Check the temperature on the thermostat located inside the refrigerator.

To determine whether or not the thermostat is working properly, set the temperature to the lowest possible level and then remove the thermistor from the device.

If the refrigerator is able to be cooled, this indicates that the thermostat is broken and has to be replaced.

• If you try the advice and they don’t work, you should take your RV to a skilled technician so that they can inspect it and figure out how to fix the problem.

How to Change the Temperature on a Dometic RV Refrigerator

Seeing drips of water flowing from the freezer is one of the symptoms that signal you need to modify the temperature of your refrigerator.

This indicates that you need to make both the refrigerator and the freezer cooler.

If you also see ice developing within the refrigerator unit, you will need to adjust the temperature so that it is higher than it is currently set.

The knob that controls the refrigerator’s temperature is a smaller lever that should move vertically along the same fin.

Adjusting the temperature to a setting that is warmer requires moving the lever lower, while adjusting it to a setting that is colder requires moving the lever higher.

How to Remove the Door of a Dometic RV Refrigerator

• Remove the two screws that are located on the underside of the plastic in order to loosen the upper trim panel. It will make the upper hinge of the door visible.

To remove the pin, lift the hinge plate and pull it out.

• Remove the lower hinge pin from the upper door and lift it off the hinge.

• First, take the door off the lower hinge pin, and then remove the upper hinge pin from the lower hinge pin.

Tips on How to Replace the Drain Hose on a Dometic RV Refrigerator

A typical Dometic refrigerator will have a white corrugated plastic line that, as it ages and gets more brittle, might shatter or split.

If it cracks or breaks, water will leak off of the evaporator coil onto the floor, which will require you to repair the component.

Things that are necessary

• Two small zip ties • A transparent PVC tube with a diameter of half an inch and a length of roughly two feet

What must be done

1. To remove the lower access door, first turn the plastic fasteners so that they are at a right angle to each other and then tilt the door from the bottom.

2. Take off the crusty white line and put in its place a clear PVC tube that is 12 in diameter. Make every effort to remove the hose in a careful manner in order to save the sealant.

3. If the sealant is damaged in any way, remove it and replace it with silicone or RV caulk.

4. Use a zip tie to secure the connection between the clear hose and the nipple of the drain pan. Make the other zip tie into a hose holder and use it.

How to Defrost Dometic RV Fridge

It is recommended to defrost the cooling fins if ice builds up on them to a thickness of at least three millimeters.

Note: You should be careful and never remove it forcibly or use heat to speed up the defrosting process. Instead, follow the instructions in the previous sentence.

• To turn off the refrigerator, press and hold the “power” button for approximately three seconds.

• Clear out the refrigerator, including all of the food and ice cube trays, and remove any other items that may be within.

• Leave the door of the refrigerator open so that air can circulate within, which will help prevent the growth of mildew.

• Once the frost has been removed, use a dry towel to thoroughly wash down both of the cooling compartments.

How to Adjust the Temperature in Your Dometic RV Refrigerator to Become Colder

• Always ensure that your refrigerator is spotless, paying particular attention to the condenser and other moving parts.

The refrigerator functions properly when there is a free flow of air, however the presence of dust and dirt disrupts the airflow.

• When it’s particularly warm outside, you should try to load your vehicle in such a way that the part of it that contains the RV refrigerator stays in the shade.

When the temperature outside is high, it might be difficult for a refrigerator to maintain its frigid temperature.

Make sure that the interior of the RV is nice and cool so that the refrigerator can maintain its temperature.

• If you want your refrigerator to be colder, turn the thermostat down to its lowest setting.

• Ensure that your refrigerator is adequately maintained and attend to any necessary repairs.

If a refrigerator, for example, has poor door seals, there will be air leaks around the corners of the door, which will reduce the refrigerator’s overall efficiency.

What are Dometic RV refrigerator troubleshooting tips?

First and Foremost, Verify the Following:

Let’s start with the fundamentals rather than going directly into the technical aspects of the refrigerator before we do anything else.

1. Ensure RV Refrigerator’s Level:

Always check to see that the level of your RV refrigerator is correct. Due to the fact that it is an absorption refrigerator, its proper operation is dependent on gravity.

In addition to this, its tubing has a unique sloping design that was developed specifically for the purpose of facilitating the continuous circulation of the liquefied ammonia.

As a consequence of this, if the RV refrigerator is not level, its circulation will reduce, which will ultimately lead to the loss of chilling.

If this results in the refrigerator still not working properly, try leveling it. Always remember to utilize the RV’s leveling system whenever you park your automobile for an extended period of time.

2. Ensure There Is Sufficient Ventilation

In order for a refrigerator to effectively chill, there must be sufficient ventilation. A space for air should always be present between the ventilation grills and the walls, back, and top of the unit.

A refrigerator’s ability to run efficiently is directly correlated to the size of the air gap between the shelves.

As a result, if the temperature inside your Dometic RV refrigerator does not drop as it should, ensure that it has sufficient ventilation.

In addition, make sure that the ventilation grills are free of any debris and dust by inspecting them regularly and then cleaning them.

In addition to this, you shouldn’t stuff your refrigerator to the brim; leave some space around the food for air to flow.

3. Make sure to park your RV in shade

It is a well-established truth that the operation of an RV refrigerator is impacted by the temperature that is present in the surrounding environment.

Therefore, if you want to get the most out of your refrigerator, you should aim to park your RV in the shade as much as possible.

4. Check the Fuses

It is important to remember to check the fuses by unscrewing the back panel of the vent that is situated on the outside of the RV for the refrigerator.

Many insects, birds, and wasps have a propensity to make their nests in the vent of the refrigerator when your van is parked for a longer period of time.

This phenomenon is frequently observed. Therefore, exercise extreme caution when opening the vent.

Tips on How to fix it Domestic Rv refrigerator troubleshooting Problems

1. Confirm that the LP Gas (Propane) Is Working

First of all, switch your refrigerator from LP system to auto while hooking up to the AC or shore power and check if it is working.

Once you have confirmed that it is working, turn off the refrigerator, remove the cover from the vent, and verify that the propane is of an adequate strength.

In addition to this, before beginning this process, make sure that your refrigerator is set to the gas mode rather than the auto mode.

The next step is to have someone else turn it on while you listen for the sound of the propane igniting. Keep a close eye on the flame after it starts to burn; it ought to be a robust blue flame.

In the event that you do not see a robust blue flame, there is a possibility that dust or an air bubble has obstructed the burner unit.

In this instance, the situation is described as follows: In light of this, search for any dust or debris that may be present, and then remove it using a vacuum.

Now, try igniting the flame once more; if you see that the flame is still faint, this indicates that there is still debris in the burner unit, so you should clean it properly.

2. Examine the Electrical Element

To examine the electric element by default, you must first change your refrigerator’s power supply from 120V to LP.

Also, don’t forget to turn off the power from the shore so that it will only use the power from the 12V DC source and the propane. Check it out right now and see whether it’s functioning.

Now that it’s been turned off, switch the refrigerator back to the automatic setting. Check to see if it is properly linked to the AC power or the shore power.

After some time has passed, turn the appliance back on and check to see if the boiler of the refrigerator gets warm.

You will need to replace your electric element in the event that it does not work. In addition to this, you have the option of operating your refrigerator only through the LP system.

3. Inspect the Control Board

Any problem with the control board of your Dometic RV refrigerator can also prohibit it from operating as it should. In order to check this, first you need to turn off your freezer as well as your LP system.

In addition to that, make sure that both the 12V and the 120V electricity are turned off.

After that, connect the plug of any device that is no longer in use to the wires that are supplying electricity to the electric heating element by taking the plug of the appliance that is no longer in use. In this situation, you do not need to worry about the polarity because it is irrelevant.

Connect your refrigerator to both the shore power and the 12V when it reaches the point where it can be powered by a direct socket without the requirement for a control board.

If you have noticed that your refrigerator is operating normally as of late, you will need to replace the control board.

4. Make sure the cooling system is working:

Examining the cooling unit is one of the troubleshooting suggestions included in the Dometic RV refrigerator manual.

Check the back of the refrigerator to see if there is any yellow crusty satin or liquid anyplace on the rear of the appliance.

If this is the case, then your cooling unit has a leak in the ammonia line. As a result, the cooling unit needs to be replaced before it can perform its functions effectively.

5. Conduct a test on the thermistor

The thermistor is a sensor that is housed within the thermostat and is in charge of regulating the temperature inside the refrigerator.

In the event that it breaks, one of two things may happen to your refrigerator: either it would remain frozen all the time or it would cease working once it has cooled down slightly.

Consequently, in order to maintain the correct operation of your refrigerator, you will need to replace the thermostat.

To inspect the thermostat, you must first remove it from its mounting on the control board and then power on the appliance. Within the next six hours, it should be cold enough.

In conclusion, in order to safeguard one’s road trip from any kind of misfortune, one must to be familiar with these fundamental troubleshooting methods for Dometic RV refrigerators.

There are times when the problem is not as significant as it appears to be, and you may easily address it on your own without the assistance of any specialist.

That has been Rv refrigerator troubleshooting problems and we have been able to come out with ways on how to fix it. I hope it has met your search? Feel free to share it.
